YATO Handheld Thermal Imaging Camera YT-72920

SKU: HMT-14766
150.000 KD
In stock

YATO Handheld Thermal Imaging Camera YT-72920 is a compact tool for finding heat loss, water leaks, overheated electrical parts, and temperature changes. Its 96 × 96 infrared detector uses Super Resolution technology to create thermal images at an effective 240 × 240 resolution. Two measurement ranges cover temperatures from -20°C to 550°C, while the 2.4-inch colour screen provides a clear view. It can save photos and videos to the built-in 8GB memory for later checking.

Specifications

Specification Details
Brand YATO
Model YT-72920
Product Type Handheld Thermal Imaging Camera
Detector Type Uncooled VOx Microbolometer
Infrared Resolution 96 × 96 Pixels
Effective Thermal Resolution 240 × 240 Pixels
Visible Camera Resolution 640 × 480 Pixels
Temperature Range 1 -20°C to 150°C
Temperature Range 2 100°C to 550°C
Accuracy ±2°C or ±2%
Measurement Sensitivity 0.1°C
Thermal Sensitivity ≤60 mK at 25°C
Refresh Rate Up to 18 Hz
Display 2.4-Inch Colour LCD
Display Resolution 240 × 320 Pixels
Field of View 50° × 50°
Focus Fixed
Emissivity Range 0.01–1.00
Internal Memory 8GB eMMC
Available User Memory Approx. 6.5GB
Image Format JPG
Video Format MP4
Battery 3.7V 2000mAh Li-Ion
Maximum Working Time 4 Hours
Charging Port USB Type-C
Dimensions 208 × 60.9 × 75.9 mm
Weight 249.5 g

Key Features

  • Effective thermal resolution of 240 × 240 pixels.
  • Measures temperatures from -20°C to 550°C.
  • Tracks centre, highest, and lowest temperatures.
  • Adjustable emissivity suits different surfaces.
  • Five colour palettes help display temperature changes.
  • Saves thermal photos and videos.
  • Built-in 8GB memory stores inspection files.
  • Rechargeable battery provides up to four hours of use.

Image Modes

  • Thermal image
  • Visible camera image with temperature readings
  • Mixed thermal and visible image

Applications

  • Finding heat loss in buildings
  • Checking underfloor heating systems
  • Locating water and heating leaks
  • Inspecting electrical connections
  • Finding overheated machine parts
  • Checking HVAC equipment
  • Automotive fault inspection
  • Testing electronic devices

Benefits

  • Finds temperature changes without direct contact.
  • Helps locate hidden faults before repair work.
  • Light 249.5 g body is easy to carry.
  • Wide temperature range suits many inspection tasks.
  • Photo and video recording supports later review.
  • USB connection allows easy file transfer to a computer.

Package Contents

  • 1 × YATO Handheld Thermal Imaging Camera YT-72920
  • 1 × USB Type-C Cable
  • 1 × User Manual
