Bosch laser measuring device with carrying case and batteries on a white background
Bosch laser measuring device with carrying case and batteries on a white background

Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

Bosch LR7 Laser Detector

38.250 KD
In stock

Bosch LR 7 Professional is a versatile laser receiver designed to detect both green and red laser lines from compatible Bosch combination and line lasers. It features a large 8cm reception area for quick laser detection and provides visual display, LED and audible signals for accurate alignment in different lighting conditions. With fine accuracy of ±1mm and rough accuracy of ±3mm, it helps extend the working range of compatible laser tools. Its compact design and IP54 protection make it suitable for demanding professional jobsites.

Specifications

Specification Details
Model LR 7 Professional
Order Number 0 601 069 J00
Type Laser Receiver / Detector
Compatible Lasers Bosch Combi- and Line Lasers
Laser Colours Green and Red
Working Range 5–50m*
Reception Area 80mm
Reception Angle 90°
Measuring Accuracy – Fine ±1.0mm
Measuring Accuracy – Rough ±3.0mm
Power Supply 2 × 1.5V AA Batteries
Operating Time Approx. 30 hours
Protection Rating IP54
Operating Temperature -10°C to +50°C
Dimensions 73 × 28 × 137mm
Weight Approx. 0.15kg

*Working range depends on the compatible laser used and environmental conditions.

Key Features

  • Detects both green and red laser lines.
  • Large 80mm reception area for fast laser detection.
  • Visual display and LED indicators for easy alignment.
  • Audible signal with adjustable volume.
  • Fine and rough accuracy settings.
  • Suitable for compatible Bosch combination and line lasers.
  • IP54 protection against dust and splash water.
  • Compact and lightweight design.

Applications

  • Laser leveling
  • Construction alignment
  • Interior installation
  • Drywall and ceiling installation
  • Electrical and plumbing alignment
  • Outdoor laser alignment
  • Professional surveying and layout work

Package Contents

  • Bosch LR 7 Professional Laser Receiver
  • Bracket for LR 6/7 Laser Receiver
  • 2 × 1.5V AA batteries
  • Protective Bag

Safety Note

Use the Bosch LR 7 according to the manufacturer's instructions and only with compatible laser tools. Protect the receiver from impacts and avoid exposing it to conditions beyond its specified operating limits.
