Bosch GST-680 Jigsaw
Couldn't load pickup availability
Bosch GST 680 Professional is a compact corded jigsaw designed for precise cutting in wood, aluminium, steel and other materials. Its 500W motor provides a variable no-load stroke rate of 800–3,100 spm with a 20mm stroke length. The ergonomic handle, adjustable speed control and bevel cutting capability provide comfortable and controlled operation for professional woodworking, installation and construction applications.
Specifications
| Specification | Details |
|---|---|
| Brand | Bosch Professional |
| Model | GST 680 |
| Product Type | Electric Jigsaw |
| Rated Power Input | 500W |
| No-Load Stroke Rate | 800–3,100 spm |
| Stroke Length | 20mm |
| Cutting Depth in Wood | 68mm |
| Cutting Depth in Aluminium | 10mm |
| Cutting Depth in Unalloyed Steel | 3mm |
| Maximum Bevel Angle | 45° left/right |
| Tool Holder | T-Shank |
| Weight | Approx. 2.0kg |
| Voltage | 230V |
| Article Number | 3 601 EB4 0.. |
Key Features
- Powerful 500W motor
- Variable stroke rate from 800–3,100 spm
- 20mm stroke length
- Cuts wood up to 68mm
- Cuts aluminium up to 10mm
- Cuts unalloyed steel up to 3mm
- T-Shank blade holder
- Adjustable speed preselection
- Ergonomic handle with soft rubber grip
- Bevel cutting from -45° to +45°
- Suitable for straight and curved cuts
- Compact design for comfortable handling
Applications
- Cutting wood
- Cutting aluminium
- Cutting unalloyed steel
- Straight cutting
- Curved cutting
- Bevel cutting
- Cabinet installation
- Carpentry and woodworking
- Construction and renovation work
Package Contents
- Bosch GST 680 Jigsaw
- 4mm Hex key
- Anti-splinter guard
- Jigsaw blade, depending on regional variant
- Carton box, depending on selected variant
Package contents vary by regional variant.
Safety Note
Wear suitable eye, hearing and hand protection when operating the jigsaw. Secure the workpiece properly, use the correct T-Shank blade, disconnect the power before changing blades, and follow Bosch operating and safety instructions.
